EDGE EDX5000.1FD-E4 Xtreme Series Monoblock Amplifier
The EDGE Xtreme Series EDX5000.1FD-E4 represents the pinnacle of monoblock amplifier engineering, delivering massive 5000W RMS power through revolutionary full bridge Class D topology. This ultra-efficient amplifier features custom-tooled heatsinks with over-engineered fins for superior heat dissipation, ensuring reliable performance in a remarkably compact footprint.
Key Features
- Full Bridge Technology: Ultra-efficient DC to AC power conversion for maximum output
- Built-in Active Crossovers: LP/HP crossover with 15Hz-20kHz range for precise frequency control
- Bass Boost Circuit: Enhanced low-frequency response for deeper, punchier bass
- Class D Topology: Superior efficiency with minimal heat generation
- Wideband Frequency Response: Full range 15Hz-20kHz capability
- Compact Design: Maximum power in minimal installation space
Technical Specifications
- Model: EDX5000.1FD-E4
- Configuration: Monoblock
- RMS Power @ 4 Ohms: 1800 watts
- RMS Power @ 2 Ohms: 2500 watts
- RMS Power @ 1 Ohm: 5000 watts
- Maximum Power: 10000 watts
- Frequency Response: 15Hz – 20kHz
- Crossover Type: LP / HP
- Recommended Fuse: 350A external
- Dimensions: 63mm x 264mm x 232mm (2.5″ x 10.4″ x 9.1″)
Perfect for powering high-performance subwoofers, midrange drivers, or tweeters in demanding car audio installations.
