Ground Zero Audio GZTW 10F
The Ground Zero GZTW 10F represents the pinnacle of flat subwoofer engineering, combining exceptional bass performance with an ultra-shallow profile. This 10-inch powerhouse features advanced Klippel optimization and premium materials for audiophiles demanding space-efficient solutions.
Key Features
- Klippel Optimized Design: Advanced acoustic engineering ensures maximum performance and minimal distortion
- High-Strength IMPP Cone: Extremely flat profile delivers precise bass response with exceptional durability
- Shallow Installation: Only 88mm mounting depth fits in the tightest spaces without compromising power
- Copper Voice Coil: 50mm copper voice coil provides superior heat dissipation and power handling
- Resonance-Free Steel Basket: Eliminates unwanted vibrations for clean, accurate bass reproduction
- Rubber Surround: Ensures long-lasting flexibility and consistent performance
- Push Terminals: Secure, easy-to-use connection system for reliable installation
Technical Specifications
- Diameter: 25 cm / 10″
- Power Handling (RMS): 300 Watts
- Impedance: 2x 2 Ohms
- Efficiency: 87.5 dB
- Power Recommendation: 150 – 450 Watts
- Voice Coil: 50 mm / 2″ copper
- Cone Material: IMPP
- Max Excursion (Xmax): 30 mm / 1.18″
- Mounting Diameter: 232 mm / 9.13″
- Mounting Depth: 88 mm / 3.46″
- Resonance Frequency (Fs): 45.1 Hz
- Overall Quality (Qts): 0.564
- Equivalent Air Volume (Vas): 24.1 L / 0.85 cu.ft.
Perfect for vehicles with limited installation space where premium bass performance cannot be compromised.
